| DELL Latitude 3520. Product type: Notebook, Form factor: Clamshell. Processor family: Intel Core i5, Processor model: i5-1135G7. Display diagonal: 39.6 cm (15.6"), HD type: Full HD, Display resolution: 1920 x 1080 pixels. Internal memory: 8 GB, Internal memory type: DDR4-SDRAM. Total storage capacity: 512 GB, Storage media: SSD. On-board graphics adapter model: Intel Iris Xe Graphics. Operating system installed: Windows 11 Pro. Product colour: Grey. Weight: 1.79 kg |
|
| Main features | | |
| | General | |
| Product type | Notebook | |
| Form factor | Clamshell | |
| Processor family | Intel Core i5 | |
| Processor model | i5-1135G7 | |
| Display diagonal | 39.6 cm | |
| HD type | Full HD | |
| Display resolution | 1920 x 1080 pixels | |
| Internal memory | 8 GB | |
| Internal memory type | DDR4-SDRAM | |
| Total storage capacity | 512 GB | |
| Storage media | SSD | |
| On-board graphics adapter | Y | |
| On-board graphics adapter model | Intel Iris Xe Graphics | |
| Operating system installed | Windows 11 Pro | |
| Product colour | Grey | |
| Weight | 1.79 kg | |
|
| Extended details | | |
| | Processor | |
| Processor manufacturer | Intel | |
| Processor family | Intel Core i5 | |
| Processor generation | 11th gen Intel® Core™ i5 | |
| Processor model | i5-1135G7 | |
| Processor boost frequency | 4.2 GHz | |
| Processor cores | 4 | |
| Processor cache | 8 MB | |
| Processor cache type | Smart Cache | |
| Configurable TDP-up frequency | 2.4 GHz | |
| Configurable TDP-up | 28 W | |
| Configurable TDP-down | 12 W | |
| Configurable TDP-down frequency | 0.9 GHz | |
| | Network | |
| Bluetooth | Y | |
| Mobile network connection | N | |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) | |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) | |
| Antenna type | 2x2 | |
| WLAN controller model | Dell Wireless 1820 | |
| WLAN controller manufacturer | DELL | |
| Ethernet LAN | Y | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s | |
| Bluetooth version | 5.0 | |
| | Design | |
| Product type | Notebook | |
| Product colour | Grey | |
| Form factor | Clamshell | |
| Market positioning | Business | |
| | Display | |
| Display diagonal | 39.6 cm | |
| Display resolution | 1920 x 1080 pixels | |
| Touchscreen | N | |
| HD type | Full HD | |
| Panel type | WVA | |
| LED backlight | Y | |
| Native aspect ratio | 16:9 | |
| Anti-glare screen | Y | |
| Display brightness | 250 cd/m² | |
| Pixel density | 141 ppi | |
| RGB colour space | NTSC | |
| Colour gamut | 45 % | |
| Maximum refresh rate | 60 Hz | |
| Contrast ratio (typical) | 700:1 | |
| | Memory | |
| Internal memory | 8 GB | |
| Internal memory type | DDR4-SDRAM | |
| Memory clock speed | 3200 MHz | |
| Memory form factor | SO-DIMM | |
| Memory layout (slots x size) | 1 x 8 GB | |
| Memory slots | 2x SO-DIMM | |
| Maximum internal memory | 32 GB | |
| | Storage | |
| Total storage capacity | 512 GB | |
| Storage media | SSD | |
| Total SSDs capacity | 512 GB | |
| Number of SSDs installed | 1 | |
| SSD capacity | 512 GB | |
| SSD interface | NVMe,PCI Express | |
| SSD form factor | M.2 | |
| Optical drive type | N | |
| Card reader integrated | Y | |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC | |
| | Software | |
| Operating system installed | Windows 11 Pro | |
| Operating system architecture | 64-bit | |
| Operating system language | Multilingual | |
| Trial software | Microsoft Office | |
| | Graphics | |
| On-board graphics adapter | Y | |
| Discrete graphics adapter | N | |
| Discrete graphics adapter model | Not available | |
| On-board graphics adapter model | Intel Iris Xe Graphics | |
| | Weight & dimensions | |
| Weight | 1.79 kg | |
| Width | 361 mm | |
| Depth | 240.9 mm | |
| Height (front) | 1.81 cm | |
| Height (rear) | 1.81 cm | |
| | Ports & interfaces | |
| USB 2.0 ports quantity | 1 | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 | |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 | |
| Ethernet LAN (RJ-45) ports | 1 | |
| HDMI ports quantity | 1 | |
| HDMI version | 1.4a | |
| Combo headphone/mic port | Y | |
| USB Type-C DisplayPort Alternate Mode | Y | |
| USB Power Delivery | Y | |
| PowerShare | Y | |
| Number of USB ports with PowerShare support | 1 | |
| | Keyboard | |
| Pointing device | SinglePoint | |
| Numeric keypad | Y | |
| Keyboard backlit | Y | |
| | Battery | |
| Number of battery cells | 4 | |
| Battery capacity (Watt-hours) | 54 Wh | |
| Battery voltage | 15 V | |
| Battery recharge time | 4 h | |
| Fast charging | Y | |
| Battery weight | 230 g | |
| | Power | |
| AC adapter power | 65 W | |
| AC adapter frequency | 50 - 60 Hz | |
| AC adapter input voltage | 100 - 240 V | |
| | Audio | |
| Audio chip | Realtek ALC3204 | |
| Number of built-in speakers | 2 | |
| Speaker power | 2 W | |
| Built-in microphone | Y | |
| | Security | |
| Cable lock slot | Y | |
| Fingerprint reader | Y | |
| Password protection | Y | |
| | Packaging content | |
| Cables included | AC | |
| | Camera | |
| Front camera | Y | |
| Front camera resolution (numeric) | 0.92 MP | |
| Front camera resolution | 1280 x 720 pixels | |
| Front camera HD type | HD | |
| Video capturing speed | 30 fps | |
| | Processor special features | |
| Intel Trusted Execution Technology | N | |
| Intel VT-x with Extended Page Tables (EPT) | Y | |
| Intel Stable Image Platform Program (SIPP) | N | |
| Intel Software Guard Extensions (Intel SGX) | N | |
| Idle States | Y | |
| CPU configuration (max) | 1 | |
| Embedded options available | N | |
| Intel Virtualization Technology for Directed I/O (VT-d) | Y | |
| Intel Virtualization Technology (VT-x) | Y | |
| | Operational conditions | |
| Operating temperature (T-T) | 0 - 35 °C | |
| Storage temperature (T-T) | -40 - 65 °C | |
| Operating relative humidity (H-H) | 10 - 90 % | |
| Storage relative humidity (H-H) | 0 - 95 % | |
| Operating altitude | -15.2 - 3048 m | |
| Non-operating altitude | -15.2 - 10668 m | |
| Operating shock | 110 G | |
| Non-operating shock | 160 G | |
| Operating vibration | 0.66 G | |
| Non-operating vibration | 1.3 G | |
|
|
